amsh89es335

Atomos Ninja V HDMI Cables

Recommended Posts

I pre-ordered the Atomos Ninja V recorder to go with my GH5S. I noticed that Atomos is recommending there HDMI cables to guarantee no issues with 4k 60p. But there $90 and $150 for one HDMI cable.

Does anyone know how necessary there hdmi cables are? Is anyone having issues with the other Atomos Recorders at 4k 60p with non Atomos HDMI cables on the GH5 or GH5S? Any recommended HDMI cables brands that are not insanely expensive?

Share this post


Link to post
Share on other sites
EOSHD Pro Color for Sony cameras EOSHD Pro LOG for Sony CamerasEOSHD C-LOG and Film Profiles for All Canon DSLRs

Panasonic says you only need am high speed HDMI cable however there are certified premium high speed HDMI cables as well cost around £20 here in UK.

There are only three types of HDMI cables standard, high speed and ultra high speed.

High speed supports up to 18 gbps and I doubt you need more

although hdmi connectors have versions 1.4 2.0b 2.1 the cables do not follow the same logic so don’t get ripped off

Share this post


Link to post
Share on other sites

This from Mystery Box:

HDMI Note
Your HDMI cables need to support HDMI 2.0 (18Gbps) or higher for 50p or 60p capture.  Many inexpensive HDMI cables are not capable of achieving the listed standard speed, so be sure to test any cables you plan on using with the GH5S and the Ninja Inferno to ensure they support 4K 60P / 4K 50P 10bit 4:2:2 transmission.  If the cable doesn’t support it, you’ll notice the Ninja Inferno cutting out and flickering during capture, and segmenting the ProRes clips as if you had started and stopped the camera each time.

We brought in multiple brands of HDMI cables, and found that the Rocketfish cables gave us the best results.

Share this post


Link to post
Share on other sites
9 minutes ago, interceptor121 said:

HDMI cables are not aligned to adapters they are just cables



https://www.hdmi.org/consumer/finding_right_cable.aspx

Then the build quality may differ but there isn’t a 2.0 cable or 2.1 there is high speed and ultra

premium certified are high speed cables with special protection for EMI

The OP asked for advice about purchasing cables that were not insanely expensive, which is what I did.

I really don't understand what you're getting at.



Share this post


Link to post
Share on other sites

What am getting at is that performance wise the amazon cable $5 is the same of $100 gold plated the specs are the same

the difference may be in build quality and how rugged the cable is

not if it can or not support the data stream or hrmi 1.4 vs 2 or 2.1

so it is not necessary to buy any special cable you just need a high speed HDMI







OMARS Premium Certified HDMI Cable 1m Ultra Speed High Support 21Gbps [email protected] (HDMI V2.0b) https://www.amazon.co.uk/dp/B01MDTOA8R/ref=cm_sw_r_cp_api_JeZoBbG2W1AY4

£7.99

Share this post


Link to post
Share on other sites
7 hours ago, interceptor121 said:

What am getting at is that performance wise the amazon cable $5 is the same of $100 gold plated the specs are the same

the difference may be in build quality and how rugged the cable is

not if it can or not support the data stream or hrmi 1.4 vs 2 or 2.1

so it is not necessary to buy any special cable you just need a high speed HDMI







OMARS Premium Certified HDMI Cable 1m Ultra Speed High Support 21Gbps [email protected] (HDMI V2.0b) https://www.amazon.co.uk/dp/B01MDTOA8R/ref=cm_sw_r_cp_api_JeZoBbG2W1AY4

£7.99

Premium Certified and £7.99 doesn't seem to go together LoL . I don't  know about that. Yeah and if it fails right in the middle of a shoot, ehh not so sure about one that cheap. There has to be some middle ground.

I thinking about it.



Funny Dog.gif

Share this post


Link to post
Share on other sites
4 minutes ago, webrunner5 said:

Premium Certified and £7.99 doesn't seem to go together LoL .Yeah and if it fails right in the middle of a shoot, ehh not so sure about one that cheap. There has to be some middle ground.

And 1 meter might be a bit excessive for most of us hybrid shooters.

Share this post


Link to post
Share on other sites

HDMI cables are not rocket science and are consumer items so they are cheap

it is up to the op to spend $10 for a cable a bit longer than needed or spend $50 for another that may have better ergonomics but has exactly the same performance

that reminds me of discussions on analog speakers cables and what a difference they made on hi fi sound quality however HDMI is digital signal so the whole idea that you need to spend a fortune on cables doesn’t really apply to signal quality is more build quality and robustness

Share this post


Link to post
Share on other sites

Yeah but you can get too damn cheap on stuff. There Has to be a reason it is cheap. I mean you have thousands of bucks tied up and you are going to spend 10 bucks for a HDMI cable??

There is video after video on YT that shows broken HDMI cables and worse, it screwed up you camera HDMI connector. Then you are Really screwed.

If you go on the Sony website they say a lot of the cheap USB cables are missing one wire on them. To Only use the Sony stuff to do Firmware updates.  And you know what they are right. I just tried to update my Sony A7s Firmware with 3 USB cables I had laying around, none of them name brands and none would work. I went down to Wal Mart and bought a 15 dollar Samsung micro USB cable and it worked the very first time I plugged it in, and the connection was a TON better fit. Wal Mart has some USB cables as cheap as 4 dollars. Probably the same crap I already had. I threw all 3 of the cheap ones in the garbage, and they is what they were, Garbage!

Share this post


Link to post
Share on other sites

I do not mean $10 cheap. But $90 to $150 for a cable, that is way over priced. They'll break and get lost on shoots, all HDMI cables eventually do. I am trying to be cautious with money, I like to have multiple redundancies as back up for every gear item I own. But when a little item like that can cost me $150 every shoot because of camera crew losing them or breaking them I need to do my homework into ones that make logical economic sense. Reliability and cost effectiveness.

I am well aware of cheap are not being safe but in the world of HDMI Cables I am trying to figure out what is cheap and what is not and what is way overpriced because Atomos can market it that way.

So if I can just get help with finding alternatives that people have had experience or know of some reviews that have been made would be much appreciated than being off topic about people being to cheap and being screwed.

Can we turn this post into a useful productive list for known HDMI cables to be reliable and work with Atomos Recorders at 4k 60p  with the GH5 and GH5s. Also that would be between 1.5ft to 3ft and not cost $150.

Here I can start the list here from what I have learned and people can build upon it based off of there own experience or reviews they share. Lets not just based it off of specs listed from unknown amazon brands and argue about them.

At the top we have the Atomos Cables.

Atomos AtomFLEX HDMI (Type-A) Male to HDMI (Type-A) Male Coiled Cable (16 to 32") $149

https://www.bhphotovideo.com/c/product/1250778-REG/atomos_atom4k60c6_hdmi_type_a_male_to.html

Atomos AtomFLEX HDMI (Type-A) Male to HDMI (Type-A) Male Coiled Cable (12 to 24") $89

https://www.bhphotovideo.com/c/product/1250777-REG/atomos_atom4k60c5_hdmi_type_a_male_to.html

jonpais was kind enough to share his experience, trial and error with cables and has had success with Rocketfish HDMI Cables.

Rocketfish™ - 1.5' 4K Ultra HD In-Wall HDMI Cable - Black $19.99

https://www.bestbuy.com/site/rocketfish-1-5-4k-ultra-hd-in-wall-hdmi-cable-black/2059068.p?skuId=2059068

Rocketfish™ - 4' 4K Ultra HD In-Wall HDMI Cable - Black $29.99

https://www.bestbuy.com/site/rocketfish-4-4k-ultra-hd-in-wall-hdmi-cable-black/3720002.p?skuId=3720002

Share this post


Link to post
Share on other sites

I would imagine Any HDMI cable that has a Name you recognize is a good one. Sony, Panasonic, Samsung, on and on. Almost every one of those cheap ones on Amazon are the same HDMI cable with a different name you never heard of, or associate the name with cheap ass stuff.

When I looked up Rocketfish on Amazon it looks to me they make kind of cheap overpriced stuff also.

https://www.amazon.com/Rocketfish/b/ref=bl_dp_s_web_2530318011?ie=UTF8&node=2530318011&field-lbr_brands_browse-bin=Rocketfish

Share this post


Link to post
Share on other sites
57 minutes ago, webrunner5 said:

I would imagine Any HDMI cable that has a Name you recognize is a good one. Sony, Panasonic, Samsung, on and on. Almost every one of those cheap ones on Amazon are the same HDMI cable with a different name you never heard of, or associate the name with cheap ass stuff.

When I looked up Rocketfish on Amazon it looks to me they make kind of cheap overpriced stuff also.

https://www.amazon.com/Rocketfish/b/ref=bl_dp_s_web_2530318011?ie=UTF8&node=2530318011&field-lbr_brands_browse-bin=Rocketfish

Do you have a specific one you have used with the Atomos Recorder and the GH5 or GH5S at 4k 60p and recommend?

Share this post


Link to post
Share on other sites
1 hour ago, amsh89es335 said:

Do you have a specific one you have used with the Atomos Recorder and the GH5 or GH5S at 4k 60p and recommend?

If you read the questions in this link you will find it is nearly your Only option for 10 bit 4K. Open up the first one in the Q&A section.

https://www.bhphotovideo.com/c/product/1250777-REG/atomos_atom4k60c5_hdmi_type_a_male_to.html

Share this post


Link to post
Share on other sites

If you look on the rocketfish $20 cable it says HDMI premium which is what I mentioned

The list if certified vendors is here

https://www.hdmi.org/learningcenter/Premium_HDMI_Cable_Participant_List.aspx

None of Sony or Apple or other major brands directly manufacturers cables so whatever you buy is almost guaranteed to be made in China

I would say $20 is pretty high already for something that costs couple of dollars to make but if you have the right ergomics would be OK

I personally would not spend more than that and the GH5 manual simply recommends a high speed cable so it is not going above the 18 GBPS Speed

If you look at the atomos one which is coiled I doesnt even specify a bandwidth and atomos is not HDMI premium certified their cable despite the brand trust doesn’t provide the only piece of information that is actually mandatory on the GH5 manual. Is that not weird?

And the other length is $29.99?

In UK is £16.45 and review rating is average to low

Atomos ATOMCAB010 HMDI Coiled Cable, Full HDMI to Full HDMI https://www.amazon.co.uk/dp/B00NUPYNUU/ref=cm_sw_r_cp_api_wF-oBbEBYXC67







Share this post


Link to post
Share on other sites
1 hour ago, webrunner5 said:

If you read the questions in this link you will find it is nearly your Only option for 10 bit 4K. Open up the first one in the Q&A section.

https://www.bhphotovideo.com/c/product/1250777-REG/atomos_atom4k60c5_hdmi_type_a_male_to.html

Take those with a grain of salt. I have been bought off buy a company to have b&h photo remove a negative review I posted about there product.

Share this post


Link to post
Share on other sites
1 hour ago, interceptor121 said:

In UK is £16.45 and review rating is average to low

Atomos ATOMCAB010 HMDI Coiled Cable, Full HDMI to Full HDMI https://www.amazon.co.uk/dp/B00NUPYNUU/ref=cm_sw_r_cp_api_wF-oBbEBYXC67

If it is like the US Amazon half the shit on there is fake stuff calming to be the real thing.







Share this post


Link to post
Share on other sites
